JYRO PLUS
ROTAVATOR
Disclaimer: These photographs are for illustrative purposes only and may be subject to change.
Our specially designed ultra light-weight puddling special rotavator puts less load on the tractor and allows faster and more effective tillage. The double-sided tempered blades give better soil pulverization and extra life, making it most suitable for paddy crop.
SPECIFICATIONS
| Model | 5 ft | 6 ft | 7 ft |
| Side Drive | Side Drive (Gear) | ||
| Type of blade | L type - Japanese technology | ||
| No. of Blades | 48 | 54 | 60 |
| Dimensions | |||
| Cutting width (mm) | 1495 | 1718 | 1968 |
| Overall width (mm) | 1750 | 2000 | 2250 |
| Overall Height (mm) | 1050 | ||
| Tractor Power (HP) | 35-40 | 40-45 | 45-60 |
| Type of Gear Box | 4 Speed | ||
| RPM on Rotor Shaft | Z15x18-180 Z16x17-203 Z17x16-230 Z18x15-259 | ||
| Weight (Kg) | 394 | 417 | 451 |
