REVERSE-FORWARD
ROTAVATOR
Disclaimer: These photographs are for illustrative purposes only and may be subject to change.
Reverse Forward Specially use in the Sugarcane Crop to Provide Strength to Sugarcane Roots.
SPECIFICATIONS
| Model | 2.5ft - 2 Point linkage | 3ft -2 Point linkage | 2.5ft- 3 Point Linkage | 3ft -3 Point linkage |
| Side Drive | Chain drive | Chain drive | Chain drive | Chain drive |
| Type of blade | J pocket -Japanese make | |||
| No. of Blades | 16 | 22 | 16 | 22 |
| Dimensions | ||||
| Cutting width (mm) | 594 | 810 | 594 | 810 |
| Over all width (mm) | 812 | 1041 | 812 | 1041 |
| Over all Height (mm) | 864 | 864 | 1010 | 1010 |
| Tractor Power (HP) | 15 - 28 | 20 - 28 | 15 - 28 | 20 - 28 |
| Type of Gear Box | Single speed | |||
| RPM on Rotor Shaft | 249 | |||
| Weight (Kg) | 154 | 160 | 154 | 160 |
