DC-99G
HARVESTER
Disclaimer: These photographs are for illustrative purposes only and may be subject to change.
The Kubota combine harvester DC-99G is a specialized machine designed for efficient paddy harvesting. It has a reliable Kubota diesel engine (98.3 HP) with 4 cylinders and liquid cooled. The DC-99G has a maximum travel speed of 2.10 m/sec with a wide cutting width of 2.18 m. It has a large grain tank with capacity of 1800 litres (approximately 1080 Kg or 1.8 m³).The harvester is equipped with a long (1,960 mm) and large-diameter (620 mm) threshing cylinder for effective grain separation. It also offers a spacious operator's cabin with superior visibility and high-lug crawlers, making it a perfect machine for harvesting in deep and moderate wetland fields.
SPECIFICATIONS
| Model | DC-99G | ||
| Machine dimensions | |||
| Overall length (mm) | 5430 | ||
| Overall width (mm) | 2422 | ||
| Overall height (mm) [with canopy stored] | 2830 [2650] | ||
| Machinery mass (Kg) | 3875 | ||
| ENGINE | |||
| Model | V3800DI-TE2-CT-3 | ||
| Type | Water-cooled four-cycle four-cylinder vertical diesel engine [with turbocharger] | ||
| Total Displacement L(cc) | 3.769 (3769) | ||
| Power Output/ rotation speed (kW{HP}/rpm) | 73.3 (98.3) / 2600 | ||
| Fuel Tank Capacity (L) | 120 | ||
| Traveling portion | |||
| Crawler | |||
| Width x Ground contact length (mm) | 500 x 1890 | ||
| Average ground pressure (kPa{kgf/cm²}) | 18.3 {0.186} | ||
| Minimum ground clearance (mm) | 330 | ||
| No. of gears | Stepless forward and reverse (3-step range gear shift each for forward and reverse | ||
| Travelling speed (m/s) | |||
| Low | 0.86 | ||
| Medium | 1.36 | ||
| High | 2.1 | ||
| Turning system | |||
| Reaper portion | |||
| Reel | |||
| Rotation diameter x No. of tine bars | 900 x 5 | ||
| Feeder tension adjustment method | Auto-tension | ||
| Reaping width (mm) | 2182 | ||
| Reaping height range (mm) | -19 to 950 (cutting blade edge) | ||
| Thresher Section | |||
| Threshing Bar (mm) | 620 x 1960 | ||
| No. of concave | 6 | ||
| Chaffer sieve width x length (mm) | 840 x 1500 | ||
| Sorting system | Oscilating, 3 way air stream cleaning system | ||
| Grain Tank | |||
| Capacity (L/Kg/m³) | 1800/approx. 1080/1.8 | ||
